MD-S910 High precision Water Oil Gas Intelligent Adjustable Digital Air Pressure Controller

FOB Reference Price:Get Latest Price
$29.00 - $60.00 / Piece | 1.0 Piece/Pieces (Min. Order)
Accuracy:
1%FS
Connection Location:
Radial Direction Mounting
Dial Diameter:
80mm
Type:
Digital Pressure Controller
Lead Time:
Quantity(Pieces) 1 - 10 11 - 50 51 - 100 >100
Est. Time(days) 3 5 10 Negotiable
Customization:
Customized logo (Min. Order: 500 Pieces)
Customized packaging (Min. Order: 500 Pieces)

More

Graphic customization (Min. Order: 500 Pieces) Less
Samples:
$39.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China
Brand Name:
Meokon
Model Number:
MD-S910
Product type:
Air Pressure Controller
Pressure range:
0-0.16...0.25...60 MPa
Accuracy:
1%FS
Connecting Thread:
M20*1.5 G1/4 G1/2 NPT1/2 NPT1/4
Shell:
Engineering Plastic
Connector Material:
304 Stainless Steel
Application:
Liquid or gas
Mounting:
Radial Direction Mounting
Supply:
24VDC,220VAC, 380VAC (Selectable)
Weight:
0.5Kg
Supply Ability
Supply Ability:
2000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Standard pressure indicator transmitter export packing or follow the customer' requirements
Port
Shanghai
Lead Time :
Quantity(Pieces) 1 - 10 11 - 50 51 - 100 >100
Est. Time(days) 3 5 10 To be negotiated

Product Description



         MD-S910 is a intelligent digital air pressure controller setting pressure measurement, pressure display, control in one professional unit. It has followed features: easy operation, good shock resistance, high precision, control range adjustable, long-term stability.

        MD-S910 digital air pressure controller has the followed functions: delay control, reverse control, three pressure units to change, one key to error clearing. It is widely used in water supply of building, air compressor, automatic machinery.

        The shell uses engineering plastic. The pressure connector is stainless steel. The product uses ceramic sensor chip to keep it good quality.

SPECIFICATION:(MD-S910 Digital Air Pressure Controller)



Range

0-0.16...0.25...60 MPa

Over Pressure 150%
Acc.  1%FS
Alarm Point Alarm point be set discretionarily within the range.

Alarm Type

Relay signal
Long-term Stability Typical:  ±0.5%FS/year
Operating Temperature  -20~ 80℃
Compensation Temperature  -10 ~60 ℃
Electric Protection Short-circuit protection, reverse protection, anti-electromagnetic interference
Sampling Frequency 5 times/sec
Measurement Medium Gas, water, oil
Pressure Connection  M20*1.5, G1/4, G1/2, NPT1/2, NPT1/4
Connector Material 304SS
Shell

Engineering Plastic

Supply  24VDC, 220VAC, 380VAC
Weight 0.5Kg



APPLICATION:(MD-S910 Digital Air Pressure Controller)

  • Pump Control
  • Air Compressor
  • Automatic Machinery

FEATURES:(MD-S910 Digital Air Pressure Controller)

  • 4 digit LED to show pressure in real time
  • Three pressure units available ( psi, Kgf/cm2 , MPa)
  • Relay signal output, upper and lower limit adjustable
  • Delay control, reverse control, pressure leakage protection, passwords protection
